- CCTV Camera
- Image Sensor: 1/2.7″ CMOS
- Effective Pixels: 1920(H)×1080(V), 2MP
- Scanning System: Progressive
- Electronic Shutter Speed: PAL: 1/25~1/100000s
- NTSC: 1/30~1/100000s
- Minimum Illumination: 0.02Lux/F1.85, 30IRE, 0Lux IR on
- S/N Ratio: More than 65dB
- IR Distance: Up to 20m (66feet)
- IR On/Off Control: Auto / Manual
- IR LEDs: 12
2. Lens
- Lens Type: Fixed lens / Fixed iris
- Mount Type: Board-in
- Focal Length: 3.6mm (2.8mm, 6mm Optional)
- Max Aperture: F1.85
- Angle of View H: 87.5° (103°, 54.7°)
- Focus Control :N/A
- Close Focus Distance: 500mm (900mm, 2000mm), 19.69” (35.43″, 78.74”)
3. Pan / Tilt / Rotation
- Pan/Tilt/Rotation: Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotation: 0° ~ 360°
4. Video
- Resolution: 1080P (1920×1080)
- Frame Rate: 25/30fps@1080P, 25/30/50/60fps@720P
- Video Output: 1-channel BNC high definition video output / CVBS
- video output: (Can switch)
- Day/Night Auto: (ICR) / Manual
- OSD Menu: Multi-language
- BLC Mode: BLC / HLC / DWDR
- WDR: DWDR
- Gain Control: AGC
- Noise Reduction: 2D
- White Balance: Auto / Manual
- Smart IR: Auto / Manual
5. Certifications
- Certifications: CE (EN55032, EN55024, EN50130-4), FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014), UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
6. Interface
- Audio Interface: N/A
7. Electrical
- Power Supply: 12V DC ±30%
- Power Consumption: Max 3.3W (12V DC, IR on)
8. Environmental
- Operating Conditions: -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
* Start up should be done at above -40°C (-40°F) - Storage Conditions: -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
- Ingress Protection & Vandal Resistance: IP67
9.Construction
- Casing: Plastic
- Dimensions: 154.3mm×69.8mm×69.8mm (6.07″×2.75″×2.75″)
- Net Weight: 0.15kg (0.33lb)
- Gross Weight: 0.22kg (0.47lb)
